Elite Pedestal 22″-32″ Adjustable
The Elite pedestal is an aluminum air-ride system with adjustable height and has up to 10″ of height adjustment.
Bentleys part # 102202
Features:
- Top Of Inner Post Has 4″ Collar Sized And Punched To Fit Any Springfield Marine Air-Ride Compatible Slide & Swivel
- Aluminum Clamp Prevents Movement Between Outer And Inner Posts For Wobble Free Ride
- 12″ Cast Aluminum Polished Base
- 11″ Hole Pattern, 6 Fasteners
- 3-1/2″ Aluminum Inner Post, .213″ Wall Thickness, Anodized With 4 Grooves Matching Clamp Keys
- 4″ Aluminum Outer Post, .213″ Wall Thickness, Brite Dip Anodized, Pressed And Welded In Base
Elite Drop Down Footrest
This attractive footrest attaches to the bottom of the chair and not the pedestal. It drops down to a comfortable 13-1/2″ below the bottom of the chair, provides a solid footing, and then folds up and out of the way if needed.
Bentley’s part# 102211
Features:
- Easily mounts to the bottom of the chair for a quick installation (hardware not included)
- Made of polished high strength aluminum construction
- 8-1/2″ x 13-1/2″
- Flips up for an out-of-the-way storage
Magnum LX
Standard Features:
- Powder coated welded aluminum folding y-bracket
- Flame laminated Ultraleather (over 75 color choices)
- Blend of high resilient foam with memory foam on seating surfaces
- Adjustable headrest
- ¾ MDO plywood
Options:
- Reclining r-bracket
- Seaboard upgrade
- 24″ stationary pedestal with swivel/slider or 24″-32″ adjustable pedestal with swivel/slider
- Flip up footrest or Slide out footrest
Dimensions:
- Overall width – 27”
- Width inside arm to inside arm – 18”
- Overall depth – 31”
- Cushion depth – 19”
- Height – 28”
- Shipping box – 28 x 25 x 25
- Shipping weight – approx. 43 lbs
Pacifica
Standard Features:
- Powder coated welded aluminum folding y-bracket
- Flame laminated Ultraleather (over 75 color choices)
- Blend of high resilient foam with memory foam on seating surfaces
- ¾” MDO plywood
Options:
- Reclining r-bracket
- Adjustable headrest
- 24″ stationary pedestal with swivel/slider or 24″-32″ adjustable pedestal with swivel/slider
- Flip up footrest or Slide out footrest
- Seaboard upgrade
Dimensions:
- Overall width – 26”
- Width inside arm to inside arm – 18”
- Overall depth – 30”
- Cushion depth – 20”
- Height – 28”
- Shipping box – 28 x 25 x 25
- Shipping weight – approx. 41 lbs
Navigator
Standard Features:
- Powder coated welded aluminum folding y-bracket
- Flame laminated Ultraleather (over 75 color choices)
- Blend of high resilient foam with memory foam on seating surfaces
- ¾ MDO plywood
Options:
- Reclining r-bracket
- Adjustable headrest
- Pedestal
- Flip up footrest
- Seaboard upgrade
Dimensions:
- Overall width – 26”
- Width inside arm to inside arm – 18”
- Overall depth – 30”
- Cushion depth – 20”
- Height – 25”
- Shipping box – 28 x 25 x 25
- Shipping weight – approx 41 lbs
Admiral
Standard Features:
- Powder coated welded aluminum folding y-bracket
- Flame laminated Ultraleather (over 75 color choices)
- Blend of high resilient foam with memory foam on seating surfaces
- ¾ MDO plywood
Options:
- Reclining r-bracket
- Adjustable headrest
- Seaboard upgrade
- Pedestal
- Flip up footrest
Dimensions:
- Overall width – 27”
- Width inside arm to inside arm – 18”
- Overall depth – 31”
- Cushion depth – 20”
- Overall height – 26”
- Shipping box – 28 x 25 x 25
- Shipping weight – approx. 41 lbs
Elite Slide Out Footrest
This elegant footrest slides fowards and backwards for the ultimate comfort form factor. It has multiple adjustments for extension. The top of the footrest is made from polyboard with grooves in it for traction.
Bentley’s part# 102211
Features:
- Fits on 4″ post
- Large 20″ x 7″ platform in an arc sweep
- Bottom clamp providing height adjustment and stability, the footrest can swivel to match chair rotation without affecting the height
- With 8″ of slide travel, the footrest stores easily under the chair, allowing the user to stand in front of the chair without interference
- Note: Can only be used on the Fixed Pedestal
Elite 24″ Stationary Pedestal w/ Swivel and Slider
Swivel:
For the most demanding work boat or pleasure boat applications, Springfield Marine’s Heavy-Duty Slide and Swivel is designed for a fixed pedestal. Offers superior design for rugged service and wobble free control.
Bentley’s part#
Features:
- 1/4″ thick aluminum swivel plate
- 10-1/2″ x 14-1/2″ x 1/4″ aluminum formed slide plate
- Cast, milled, and anodized swivel clamps.
- Locks onto a 4″ post with a stainless steel pin
- Swivel rotates internally on 1/2″ HDPE bearings for a smooth operation in any position
- Three lock nut backed bolts provide tension adjustment on the swivel bearing to eliminate any unwanted movement
- Swivel control handle has a lockout Position, that allows for a free swivel operation
- Large, easy to reach and grip control knobs
- Smooth, precise movement in both the slide and swivel operations
- 6-7/8″ of total slide travel
- Anodized finish
Pedestal:
This recently redesigned elite aluminum fixed height pedestal is very sturdy and a lovely compliment to your elite seat.
- 12″ diameter polished aluminum cast base
- 11″ hole pattern and 6 fasteners
- 24″ pedestal
- 4″ diameter brite dip anodized aluminum post, .213″ wall thickness
- Post is sized and pressed into base, then rim welded for stability
